+Crossvent 2i

کشور سازنده:
USA
استاندارد:
FDA,CE,ISO 13485,FM 71213
محل استفاده:
، ،

توضیحات

Features

The Crossvent 2i+ Stand-Alone infant ventilator features patient-triggered ventilation using a proximal flow sensor sensitive enough to allow the smallest of patients to trigger the vent. The flow sensor (pneumotach) also accurately measures the patient’s exhaled tidal volume down to 2.0 ml. The built-in rechargeable nickel metal hydride battery provides at least 3 hours of run time on a full charge (back light can also be dimmed to greatly extend this battery life). The vent features a touch screen display that is visible under all lighting conditions, and a full complement of alarm parameters.



Ventilation Modes

Pulsatile/Constant Flow
Assist Control
SIMV
CPAP
Pressure Support
Flow Trigger



Dimensions & Weight
Height 10″ (25.4 cm)
Width 11″ (28.0 cm) or 13.5″ (34.3 cm) with optional mounted blender
Depth 4.4″ (11.2cm)
Weight 10.5 lbs (4.8 kg) or 13.5 lbs (6.1kg) with optional mounted blender




Rate: 5-150

Tidal Volume: 5-750

Inspiratory Time: 0.10 – 3.0 seconds

Flow Rate: 1-15 lpm

Peak Pressure: 0-80 cmH2O

PEEP: 0-20 cmH2O

Flow Trigger: 0-20 (sensitivity scale)

Base Flow: 2.5 lpm

Pressure Support: 0-50 cmH2O

SIMV Rate: 0.6 – 50 bpm

Continuous Flow: 0-15 lpm

Pneumatic Power Source: 17-55 psi (117-380 kPa)

O2 Sensor: 21-100%
